Pin Hanger Assembly
0-6588* and A-14966**
."'>.
'®TYP.
9
Item Part Number
Description
Item Pari Number
Description
1 A-65S7
Pin Hanger Brackel Assy
16 12-6351
R.O. Wire Form
2 A-6S67
Coil Stop Assembly
17 12-6371
Pin Hanger Wire
3 SB-28-1450-DC" Coil Assembly
18 20-8712-25
"E" Ring, 1/4" Shaft
or
19 4008-01017-04 Mach. Screw. 8-32 x
1/4
8-31-2500""
20 4010-01025-14 Mach. Screw. 10-32 x 7/8
4 01-3869
Pin Reset Mounting Brkt.
21 4104-01001-06 Sh. Metal Screw. #4 x
3/8
5 02-3137
Main Lever Shaft
22 4410-01130-00 Nut, 10-32 Hex.
6 02-3138
Pin Suspension Shaft
23 4700-00011-00 Flatwasher, 11/64 x 7/16 x 16ga.
7 02-3140
Solenoid Plunger
24 4700-00103-00 Flatwasher, 17/64 x
1/2
x 28 gao
B
02-3141
Trip Actuator Shaft
25 4701-00004-00
Lockwasher. #10 Split
9 03-7201
Pin Hanger
26 10-295
Main Spring
10 03-7202
Pin Reset Lever
27 12-6357
Reinforcing C~p
11 03-7203
Pin Release Latch
28 4106-01019-06 Sh. Metal Screw. #6 x 3/8
12 03-7204
Reset Lever
29 4106-01022-12 Sh. Metal Screw. #6 x
3/4
13 03-7205
Pin Trip Actuator
30 31-1445
Bowling Pin. #4801
14
10-255
Secondary Lever Spring
15 10-321
Secondary Lever Spring
"Used on Shuffle Inn Series
"Used on Strike Master Series
8-18
