Page 687 - Williams RED Parts Catalog 16-9190-B

SEO Version

Pin Panel Assembly
Game#-PP
Item Part Number
Description
Item Part Number
Description
1 02-3325
Reset Bar - Rear
13 0-6588*
Pin Hanger Assembly
2 01-3895
Guide, Pin Hanger
or
3 a) 01-5325
Reset Bar Support
A-14966 ••••
b) 23-6313
Rubber Grommet
14 20-8749-8
Fluorescent Ballast
4 C-12096-1
Pin Panel Motor Ass'y
15 20-8748-1
Fluorescent Starter
5 12-6410
Reset Wire
16 20-8747
Starter Fixture
6 12-6394
Reset Wire
17 01-3822-2
Fluorescent Reflector
7 C-13088·
Triac Driver
18 24-6597-5
Fluorescent Lamp
or
19 20-8746
Fluor. Lamp Holder
A-13088-2"·
20 01-3827-5
Fluor. Mounting Bracket
8 12-6393
Reset Wire
21 01-6687
Pin Panel Front Brace
9 01-3896
Spring Hanger-Pin Panel
22 20-8790-7
Nylined Bearing
10 10-295
Main Spring
23 20-8712-25
"P Ring,
1/4"
Shaft
11 01-3710-A1
Arm - Reset B~r
24 23-6450
Foam Rubber
1/2
x
3/4
12 A-6821
Bracket
&
Stud Ass'y
25 0-12328
23-Lamp PC Board
"Used on Shuffle Inn Series
"'Used on Strike Master Series
O)f~e
