(50003)
Ball
Guide
and Ramp Locations
Item Part Number
Description
1 A-14079
Left Flipper Return Frame
2 A-14064
Ball Guide Assembly
3 A-14080
Ball Guide Assembly
4 A-14263
Ball Guide Assembly
5
A-14332
Ball Guide Assembly
6 A-14065
Ball Guide Assembly
7 A-14069
Ball Guide Assembly
B A-13895
Left Plastic Ramp Ass'y
9 A-1406B
Ball Guide Assembly
10 A-14070
Ball Guide Assembly
11 A-14067
Ball Guide Assembly
12 A-I3894
Right Plastic Ramp Ass'y
13 A-14062
Ball Guide Assembly
14 A-14035
Ball Guide Assembly
15 A-14036
Ball Guide Assembly
16 A-14063
Oplo Ball Guide Assembly
17 A-14066
Ball Guide Assembly
18 A·14163
Ball Guide/Shaft Assembly
19 A·14156
Shooter Ramp Assembly
20 A-13966
Plastic Ramp Assembly
(MId. under Playfield)
21 A-13993
Loop Assembly
22
A-14264
Ball Guide Assembly
23 A-14190
Drain Assembly
24 A-14081
Ball Guide Assembly
25 A-14078
Right Flipper Return Frame
Located Under Bottom Arch:
26 B-8623
Upper Trough Baffle
27 01-3569-1
Ball Trough Runway
28 C-8235
Lower Trough Baffle
29 31 ·1008-50003 Screened Bottom Arch
3-4b
