Item Part No.
Description
1
A-810B-L-2
Left Flipper Return Frame
2 A-14333
Ball Guide Assembly
3 A-14334
Ball Guide Assembly
4 A-14335
Ball Guide Assembly
5
A-14336
Ball Guide Assembly
6
A-14339
Ball Guide Assembly
7 A-14319
Loop Assembly
(Mtd. under Playfield)
8 A-14362
Left Plastic Ramp Ass'y
9 A-14318
Ball Guide Assembly
10 A-14338
Ball Guide Assembly
11 A-14337
Ball Guide Assembly
12 A-14327
Ball Guide Assembly
13 A-14328
Ball Guide Assembly
14 A-14340
Ball Guide Assembly
15 A-14359
Right Plastic Ramp Ass'y
16 A-14341
Ball Guide Assembly
17 A-Bl0B-R-2
Right Flipper Return Frame
Located Under Bottom Arch:
18 B-8623
Upper Trough Baffle
19
01-3569-1
Ball Trough Runway
20 C-8235
Lower Trough Baffle
21 31-100B-50002 Screened Bottom Arch
THE~i.(~W~~
BRIDE OF
PIN" BOr
(50002)
Ball Guide and Ramp Locations
o
ELECTRONICS GAMEB.INC.
3-4a
