Page 213 - Williams RED Parts Catalog 16-9190-B

Ball Guide and Ramp Locations
(50007)
Item Part Number Description
1 8-13921-L Left Flipper Return Frame
2 0-13846 Left Plastic Ramp Ass'y
3 C-13821 Ball Guide Assembly
4 8-13845* Up/Down Ramp Assembly
5 C-13820 Ball Guide Assembly
6 C-13819 Ball Guide Assembly
7 C-13817 8all Guide Assembly
8 0-13960 Kick Ramp Assembly
9 R-13848 Plastic Multi-Ramp Ass'y
10 8-13818 8all Guide Assembly
11 8-13813 Ball Guide Assembly
12 8-14014 Ball Guide Assembly
13 8-13814 Ball Guide Assembly
14 0-13847 Right Plastic Ramp Ass'y
15 B-13921-R Right Flipper Return Frame
Located Under Bottom Arch:
16 B-8623 Upper Trough Baffle
17 01-3569-1 Ball Trough Runway
18 C-8235 Lower Trough Baffle
19 31-1008-50007 Screened Bottom Arch
*Part of Multi-Ramp Assembly R-13848.
