(574)
Ball Guide and Ramp Locations
"Part of R·13190. Ramp Assembly.
Item Part No.
1 A·13274·L
2 01·9521
3 C·13318
4 B·13319
5 8-13349
6 R-13190
7 B-13350
7a A·13360
8
0-13384
9 C·13335
10 C-l3334
11 0·13129
12 B·13333
13 C·13332
14 A·13443
15
8-13351
16 8-13399
17 A-13359
18 B-13233"
19 B·13320
20 A-13385
21 0·13383
22 C·13317
23 A·13274-R
Description
Left Flipper Return Frame
Ball Guide
Ban Guide Assembly
Ball Guide Assembly
left Cellar loop
Left Ramp Assembly
Righi Cellar loop/Runway
Ball Guide Assembly
Ball Guide Assembly
Ball Guide Assembly
Ball Guide Assembly
Rear Ramp Assembly
Ball Guide Assembly
Ball Guide Assembly
Eject Hole Ball Deflector
Ramp Entry Ball Guide -left
Ramp Entry Ball Guide - Rgt.
Ball Guide Assembly
lifting Ramp Assembly
Ball Guide Assembly
Ball Guide Assembly
Ball Guide Assembly
Ball Guide Assembly
Right Flipper Return Frame
located Under Bottom Arch:
24 8·8623
25 01-3569·1
26 C·8235
27 31·1008·574
Upper Trough Baffle
Ball Trough Runway
lower Trough Baffle
Screened Bottom Arch
3-2
