Page 190 - BallyMidway GREY Parts Catalog 16-9562-A

(50036)
CCl
Item Part Number
1 A-13204-50036
2 A-1920B-2
3 01-13023.1
4 A-1B5BB.2
5 01-13022.2
6 A-18975
7 A-18594.3
8 A-18592
9 A-18977
10 A-18967
11 A-1859l
12 A-1B593
13 01-13020
14 01-13021
15 A-18S89
16 01-13413.1
17 A-18S90
18 A-1858?1
19 A-1920B.1
Ball Guides
Description
Bottom Arch Assembly
Left Flipper Ball Gd Ass'y
Ball Guide
Ball Guide Assembly
Ball Guide
Garage Guide Weld Ass'y
Ball Guide Assembly
Ball Guide Assembly
Diverter Flag/Rivet Ass'y
Ball Guide Assembly
Ball Guide Assembly
Ball Guide Assembly
Ball Guide
Ball Guide
Ball Guide Assembly
Right Lane Divider
Ball Guide Assembly
Ball Guide Assembly
Right Flipper Ball Gd Ass'y
Mounted under Bottom Arch Assembly:
20 01-13273.1 Ball Guide
Ramp and Trough Locations
Item Part Number
A A-19140
B A-19007
C A-19009
o A-19004
E A-19154
Description
Engine/Ramp Assembly
Loop Ramp Assembly
Race Track Ramp Ass'y
Track Assembly
Exhaust Pipe (Ramp) Ass'y
Mounted Under Playfield:
F A-18753 Ball Trough Assembly
Ball Guide locations
