Page 191 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

Special Collectors Edition
(50038)
Ball Guide Locations
Ball Guides
Item Part Number
Description
1 A-13204-50038 Bottom Arch Assembly
2 A-15252-L
Left Flipper Ball Gd Ass'y
3 A-15239
Ball Guide Assembly
4
A-15199
Opto Ball Guide Ass'y
5 A-15197
Opto Ball Guide Ass'y
6 A-15242
Ball Guide Assembly
7 A-15246
Ball Guide Assembly
8 A-15241
Ball Guide Assembly
9 A-15244
Ball Guide Assembly
10 A-15247
Ball Guide Assembly
11 A-15243
Ball Guide Assembly
12 A-15240
Ball Guide Assembly
13 01-10454
Ball Deflector
14 A-15251
Ball Guide Assembly
15 A-14974
Shooter Ramp Ball Guide
16 A-15248
Ball Guide Assembly
17 A-15250
Ball Guide Assembly
18 A-1524S
Ball Guide Assembly
19 A-15252-R
Right Flipper Ball Gd Ass'y
20 A-15249
Ball Guide Assembly
Mounted under Bottom Arch:
21 B-8623
Guide
&
Baffle Assembly
22 01-3569-1
Ball Return Runway
23 01-10599
Ball Guide Runway
3-?f
(jJafPLt
/MIDWAY
