Item Part Number
1 A-13204-50032
2 01-12915
3 A-19B76-2
4 01-12921
5 A-18512
B A-1906B
7 A-18514
8 01-12916.1
9 *A-19522
10 A-19964
a)
A-19052
11 A-19061.1
12 A-19679
13 A-19060
14 A-18515
15 01-19218
16 A-19676-1
17 A-18513.1
Ball Guide and Ramp Locations
(50032)
Ball Guides
Description
Bottom Arch Assembly
Left Drain Ball Guide
Left Flipper 8all Gd Ass'y
Ball Guide
Upper Loop Ball Gd Ass'y
Left Popper Ball Gd Ass'y
Main Loop Short Ball Guide
Main Loop Long Ball Guide
Ball Deflector Assembly
Sanctum Rubber Assembly
Inner Sanctum B/Gd, Left
8all Guide Assembly
Ball Stop Oeflector Ass'y
Ball Guide Assembly
Inner Sanctum B/Gd, Rgt.
Upper Flipper Ball Guide
Right Flipper Ball Gd Ass'y
Right Drain Ball Guide
Mounted Under Bottom Arch Assembly:
18 01-13593
Ball Guide
Ramp and Trough Locations
Item Part Number
A A-17854
B ·03-9214
C A-17855
Description
Small Ramp Assembly
Mini Playfield Rear Ramp
Large Ramp Assembly
Mounted Under Playfield:
o
A-18753
Ball Trough Assembly
-
0000 -
00 0
a
0
o a
*Mounted on Mini Playfield Back Board Assembly.
