Bait Gate and Switch Gate Assemblies - cont'd
DEMO MAN (5002B) - cont'd
Part Number
Description
Quantity
Per Game
"A-iBHi
a) 01-10509
b) 12-6944
Related Parts:
01-8240
01-8600
01-10636
4002-011 05-08
5070-09054-00
5647-12693-11
Ball Gale Assembly
Mounting Bracket
Wireform
Nut Plate
Insulator
Switch Cover Clip
MS 2-56
x
1/2
P-PH-S
Diode 1N4004 1.OA
Mini Micro Switch
1
""A-18255
a) 01-12679
b) 12-6944
c) 07-6688-19N
d) 31-1919-23
Related parts:
B-12224
H-18215-2
03-8022-4
03-8063-4
4006-01005-12
4406-01119-00
Ball Gate Assembly
Mounting Bracket
Wireform
Rivet .125 x 3/16 (2)
Playfield Plastic
Single Lamp Assembly
2-Pin Lamp Cable
Spacer (2)
Ught Bulb Sleeve, Red
MS 6-32
x
3/4 P-PH (2)
Nut 6-32 ESN (2)
1
See p. 3-48 for drawing.
A-19310
See
p.
3-48 for parts.
Left "Bridge Out" Switch
Gate Assembly
1
See p. 3-46 for drawing.
A-19310
See
p.
3-47 for parts.
Right 'Bridge Out" Switch
Gate Assembly
1
"Used on
Ramp
Assembly A-17786 - see
p
3-54.
"Used on Super Jackpot Assembly A-18383 (shown).
