Page 220 - Williams GREEN Parts Catalog 16-9932

Ball Gate and Switch Gate Assemblies
STAR TREK (50023) - cont'd Part Number Description
Quantity
Per Game
*A-17515
a) 01-8240
b) 01·8600
c) 01-9654-4
d) 12-7147
e) 4002-01105-08
f) 5070-09054:'00
g) 5647-12693-11
Switch Gate Assembly
Nut Plate
Insulator
Mounting Bracket
Wi reform
MS 2-56 x 1/2 P-PH-S (2)
Diode 1N4004, 1.0A
Mini Micro Switch
1
*A-17516
a) 01-8240
b) 01-8600
c) 01-9654-1
d) 12-6909-2
e) 4002-01105-08
f} 5070-09054-00
g) 5647-12693-11
Switch Gate Assembly
Nut Plate
Insulator
Mounting Bracket
Wireform
MS 2-56 x 1/2 P-PH-S (2)
Diode 1N4004, 1.0A
Mini Micro Switch
"Used on Ramp Assembly A-17015 - see p. 3-43.
ROAD SHOW (50024) Part Number Description
Quantity
Per Game
A-14196
a) 01-9935
b) 01-9936
c) 12-6953
Shooter Gate Assembly
Mounting Btracket
Shooter Gate
Hinge Pin
1
4-26 Ci)(/~ ® ELECTRONICS GAMES, INC.
