Ball Gate and Switch Gate Assemblies
INDIANA JONES
(50017)
Part Number
Description
Quantity
Per Game
(Left shown)
A-16596-1
a)
12-6657·L
b) 01-6935
c)
01·6938·'
d)
12-6882·1
Ball Gate Assembly, Lett
Wireform
Ball Gate
Mounting Bracket
Gate Hinge Pin
A·16596·2
a)
12·6657·R
b) 01·6935
c)
01-6938·1
d)
12·6882-1
A·16918
a)
01-8374-1
b)
12-7116
BaH Gate Assembly, Right
Wireform
Ball Gate
Mounting Bracket
Gate Hinge Pin
Ball Gate Assembly
Mounting Bracket
Wireform
1
STAR TREK
(50023)
Part Number
A-16959
a)
01·11688
b)
12-7118
"'A-17329
a)
01-8240
b)
01-8600
c)
01-10636
d)
01-12016
e)
03-8022-5
f)
03-8063·2
g)
03-8063-4
h)
07-6697-4
i)
12-7147
j)
31-1803-24
k)
4002-011 05-08
I)
4006-01005-14
m)
4406-01119-00
n)
5070-09054-00
0) 5647-12693-11
p)
A·17272
Description
Switch Gate Assembly
Mounting Bracket
Wireform
Switch Gate Assembly
Nut Plate
Insulator
Switch Cover Clip
Mounting Bracket
Spacer (2)
Light Bulb Sleeve, Green
Light Bulb Sleeve, Red
Rivet
.125
x
.187 (2)
Wireform
Playfield Plastic
MS 2·56
x
1/2
P·PH-S (2)
MS 6·32
x
3/4 P-RH (2)
Nut #6-32 ESNA (2)
Diode "1N4001, 1.0A
Mini Micro Switch
2-Lamp PCB Assembly
"Used
on Ramp Assembly
A·16811 -
see p.
342.
Quantity
Per Game
1
1
