Ball Guide and Ramp Locations
Ball Guides
Item Part Number Description
1 03·9068 Molded Plastic Bottom Arch
2 A·18990·2 Left Flipper Ball Guide Ass'y
3 01·1.2974.1·1 Left Divsrter Guide
4 A-17860 Ball Guide Assembly
5 A·17880 Ball Guide Assembly
6 A·19045 Ball Guide Assembly
7 03·9071 Plastic Ball Guide
8 01-12669 Platform Guide Bracket
9 A·18972 Popper Guide/Decal Ass'y
1.0 A·17863 Ball Guide Assembly
11 A·17862 Bal! Guide Assembly
12 A·17879 Ball Guide Assembly
13 A·18629 Ball GuidefGate Wire Ass'y
14 A'19077 Ball GuidefWood Rail Ass'y
15 01-12974.1·2 Right Diverter Guide
16 A·18990·1 Right Flipper Ball Guide Ass'y
01-13203 Ball Guide
Mounted under Bottom Arch:
17 01·12580 Ball Guide
'Locaticn not shown • see p. 3-24 for drawing.
Ramps and Troughs
Item Part Number
A A-18131
B A·la566
C A·18130
D A-17912
Description
Left Plastic Ramp Assembly
Plastic Ramp/Switch Assembly
Right Plastic Ramp Assembly
Metal Ramp Assembly
Mounted under Pfayfield:
E A·18753 Outhole Ball Trough Assembly
Note: See Section 4 for Wireform Ramps.
(50029)
