DEMOLITION MAN
(50028)
Ramp and Trough Locations
~
vv
[?:?A",~d
o
00
o
000 0 O·
00 00
00 0
0
0
Top View
Ramps and Troughs
Item Part Number
1 A·17786
2 03·9000
3 A·1805 7
4 A·17771
5 A·17784
6 A·17785
7 A·17291
Description
Lower Middle Ramp Ass'y
Car Tunnel Assembly
Cryo Ramp/Bracket Assembly
Feed Ramp Assembly
Diverter Ramp Assembly
Upper Middle Ramp Assembly
Inclined Ramp Assembly
Underside View in Raised Position
Mounted under Playfield:
8 A·17823
9 A·16765 ·1
10 A-17620
Ball Popper Trough Assembly
Outhole Ball Trough Assembly
Chute/Ball Popper Assembly
Note: See Section 4 for Wireform Ramps.
O)f~®
ELECTRONICS GAMES, INC.
3-7
