Page 129 - Williams GREEN Parts Catalog 16-9932

SEO Version

Item Part Number
A-13204-S0030
2 03-9216-9
3 01-13280
4 01-13785
5 A-19347.2
6 A-1960S.1
7 A-19252
8 A-19342.1
9 A-18623
10 01-13277.1
11 A-19341
12 01-13281
13 01-12937.1
14 03-921 6-9
Ball Guide and Ramp Locations
(50030)
Ball Guides
Description
Bottom Arch Assembly
Left Flipper Ball Guide,
Red Plastic (2)
Left Hole Guide
Ball Guide
Ball Guide Assembly
Ball Guide Assembly
Ball Guide/Wire Ass'y
Ball Guide Assembly
Ball Guide Assembly
Shooter Lane B/Guide, Left
Upper Flipper Guide Ass'y
Gun Ball Guide
Shooter Lane B/Guide, Right
Right Flipper Ball Guide,
Red Plastic (2)
Mounted under Bottom Arch Assembly:
15 01-13638
Ball Guide
Mounted under Playfield:
C A-18753
Outhole Ball Trough Assembly
Hem Part Number
A A-19040
B A-18604
Ramps and Troughs
Description
Left Plastic Ramp Assembly
Main Plastic Ramp Assembly
Note: See Section 4 for Wireform Ramps.
