FIREI (556)
Ball Guide and Ramp Locations
Item Part No.
Description
1 8-7537-1
Ball Guide Assembly
2 A-81S1-1
Left Return Frame
3 8-11497
Ball Guide Assembly
4 C-11505
8all Guide Assembly
5 8-11502
Left Ramp
6 C-11509
Ball Guide Assembly
7 0-11499
Horse Shoe Runway
8 C-11520
Left Fire Escape Ramp
9 C-11512
Outer 8all Guide
10 C-11513
Inner Ball Guide
11 B-11498
Horse Shoe Ball Guide
12 8-11485
Ladder Ramp Assembly
13 C-11545
Ball Guide Assembly
14 C-11519
Right Fire Escape Ramp
15 C-11511
Ball Guide Assembly
16 8-11503
Right Ramp
17 C-11507
8all Guide Assembly
18 A-11514
Ball Guide Assembly
19 01-8675
Ball Deflector
20 8-11515
Ball Guide Assembly
21 A-8151-R
Right Return Frame
22 8-11688
Ball Guide Assembly
23 B-8623
Ball Guide & Baffle
24 01-3569-1
Ball Return Runway
25 C-8235
Ball Runway
26 31-1008-556
Screened Bottom Arch
ELECTRONICS GAMES. INC.
3-45
