BIG GUNS (557)
Ball Guide and Ramp Locations
Item Part No.
Description
1 B-8239-1
Left Return Frame
2
B-11668
Ball Guide Assembly
3 8-11ns
Left Cannon Ball Guide
4 8-11669
Ball Guide Assembly
5 A-11795
Ball Guide Assembly
6 01-8646
Ball Deflector
7 A-11796
Ball Guide Assembly
8 C-11656
Ball Guide Assembly
9 A-11653
8all Guide Assembly
10 B-11790
Ball Guide Assembly
11 A-11654
8all Guide Assembly
12 C-11655
Ball Guide Assembly
13 A-11794
Ball Guide Assembly
14 B-11791
Ball Guide Assembly
15 A-11793
Ball Guide Assembly
16 8-11792
Ball Guide Assembly
17 8-11775
Right Cannon Ball Guide
18 B-11667
Ball Guide Assembly
19 A-11889
Right Return Frame
20 8-8623
Ball Guide
&
Baffle
21 01-3569-1
Ball Return Runway
22 G-8235
Ball Runway
23 31-1008-557 Screened Bottom Arch
Upper Mini-Playfield - King's Chamber
24 B-11799
Ball Guide Assembly
25 C-11801
Ball Guide Assembly
26 A-11800
Ball Guide Assembly
3-46
