Page 182 - Williams BLUE Parts Catalog 16-9064-B

TAXI (553)
Ball Guide and Ramp Locations
Item Part No. Description
1 A~12291 Ball Guide Assembly
2 B~12305 Ball Guide Assembly
3 B~12289 Ball Guide Assembly
4 B~12290 Ball Guide Assembly
5 D~12263 Left Ramp Assembly
6 A~12285 Ball Guide Assembly
7 01~8626 Ball Deflector
8 B~12294 Ball Guide Assembly
9 B~12306 Ball Guide Assembly
10 C~12286 Ball Guide Assembly
11 R~12262 Spinout Ramp
12 C~12284 Ball Guide Assembly
13 01 ~6933 Ball Deflector
00 14 C~12288 Ball Guide Assembly
15 C~12287 Ball Guide Assembly
~ 00 16 Dp 12264 Right Ramp
G~ 0 17 B~12320 Ball Guide Assembly
18 B~12292 Ball Guide Assembly
19 Bp 8623 Ball Guide & Baffle \) D 0 20 01 ~569~1 Ball Return Runway
21 C~8235 Ball Runway
22 31 ~1008~553 Screened BoHom Arch
3 p 44
