(20006)
Ball Guide and Ramp Locations
Item Part Number
Description
1 31·1008·20006 Screened Bottom Arch
2 A·15438·L
Left Return Frame Ass'y
3 01·10682
Ball Guide
4 A·15436
Main Plastic Ramp Ass'y
a)
01·10693
Ball Deflector
b)
01·10669
Ramp Ball Guide, Short
c)
01·10668
Ramp Ball Guide, Long
5 01·10683
Ball Guide
6 01·10688
Ball Guide
7 01·10689
Ball Guide
8 A·15441
Lower Level Ramp Ass'y
(Mid. under Playfield)
9
A·15354*
Ball Return Ramp Ass'y
(Mid. under Mini·Plfd)
10 01·10690
Ball Guide
11 01·1a644·L **
Left Ball Guide
12 01·10691
Ball Guide
13 01·10646·L**
Left Ball Deflector
14 01·10671**
Ball Guide Assembly (2)
15 01·10646·R**
Right Ball Deflector
16 01·1a644·R**
Right Ball Guide
17 01·10687
Ball Guide
18 A·15690
Right Plastic Ramp Ass'y
19
01·10685
Ball Guide
20 01·10673
8all Deflector
21 01·10686
Ball Guide
22
01·10684
8all Guide
23 A·15438·R
Right Return Frame Assy
Under Bottom Arch:
24 B·8623
Guide & Baffle Assembly
25
01·3569·1
Ball Return Runway
26 01·10599
8all Guide Runway
*See Sect. 5, pp. 5·91
&
5·92
**Mounted on Mini·P\ayfield
