Page 204 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

(20004)
Ball Guide and Ramp Locations
Item Part Number
Description
1
31-1008-20004
Screened Bottom Arch
2 B-12919*
Left Ball Return Frame
3 01-10375
Ball Deflector (2)
4 03-8584
Lower Left Ramp
5 A-14854
Ball Guide Assembly
6 01-6933
Ball Deflector
7 A-14984
Upper Left Ramp Ass'y
8 A-14860
Ramp Assembly
9 A-14852
Ball Guide Assembly
10
A-14853
Ball Guide Assembly
11
A-14851
Ball Guide Assembly
12 A-14858
Ball Guide Assembly
13 A-14932
Ball Guide Assembly
14 A-14857
Ball Guide Assembly
15
A-14855
Ball Guide Assembly
0
16
A-14856
Ball Guide Assembly
0
17
A-14911
Right Ramp Assembly
0
18 B-12918*
Right Ball Return Frame
0
Under Bottom Arch:
19 8-8623
Guide & Baffle Assembly
20 01~569-1
Ball Return Runway
21 C-8235
Ball Runway Assembly
·See p. 3-23 for drawings.
