Item Part Number
Description
1 31-1008-20003 Screened Bottom Arch
,-,
2 B-12852*
Left Ball Return Frame
'9'-
3 A-14555
Ball Guide Assembly
\
..••....•.
,
4 A-14552
Ramp/Ball Guide Assembly
a)
A-14550
Ramp Lift
b)
A-14551
Ball Guide
5
A·14548
Ball Guide Assembly
6 A-14549
Ball Guide Assembly
7
A·14547
Ball Guide Assembly
8 01-10229-2
Ball Deflector
9 A-14539
Ball Popper Ramp Assembly
(Mtd. under Playfield)
10 A-14556
Ball Guide Assembly
11 A-14542
Ball Guide Assembly
12 A-14543
Ball Guide Assembly
13 A-14546
Ball Guide Assembly
14 A-14538
Main Ramp Assembly
a)
01-10232
Ball Deflector
00
(See p. 3-39i)
15 01-10229-1
Ball Deflector
00 0
16 A-14544
Ball Guide Assembly
0
0
17 01-10141
Shooter Lane Entrance Ramp
~[j1J
18 A-14545
Ball Guide Assembly
19 B-13921-R
Right Ball Return Frame
Under Bottom Arch:
20 8-8623
Guide
&
Baffle Assembly
21 01-3569-1
Ball Return Runway
22 C-8235
Ball Runway Assembly
*See p. 3-19 for drawing.
(20003)
Ball Guide and Ramp Locations
