Page 202 - BallyMidway YELLOW Parts Catalog 16-9147-B

(20009)
Ball Guide and Ramp Locations
!tem Part Number Description
1 31-1008-20009 Screened Bottom Arch
2 A-14230 Left Ball Return Frame
3 A-14153 Kicker Ramp Assembly
4 A-14218 Ball Guide Assembly
5 01-9926 Ball Guide
6 01-9964 Ball Guide
7 A-14217 Ball Guide Assembly
8 A-14221 Ball Deflector
9 A-14279 Drop Down Ramp Assy.
10 A-14213 Up/Down Main Ramp Assy.
a) 03-8505 Upper Plastic Ramp
b) 03-8509 Lower Plastic Ramp
11 A-14220 Ball Guide Assembly
12 A-14223 Shooter Ramp Assembly
13 A-14219 Ball Guide Assembly
Under Bottom Arch:
14 8-8623 Guide & Baffle Assembly
15 01-3569-1 Ball Return Runway
16 C-8235 Ball Runway Assembly
3-Sf @a!fy/MIDWAY
