Page 38 - 1980_1_PARTS_ASPIRE

o
®32 1
1 0 G~32
bJ ~
o 1 {} ~
18 0
33 q
01
o
0°0
0 0 0
o 0
00 0
BACKGlASS
G440·12
26
~
o
g r- ,15
1 '- _ . .I ,
17 ,'
WHEN ORDERING PART. SPECifY PART NO. AID lAME OF GAME
38
RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excess of one.
A. R·521-2 1%" Oia. (1 )
B. R-521-' 1" Oia. (5)
C. R-521-5 3" Oia. (3)
O. R-521- '%" Oia. (3)
E. R·521·4 2%" Dia. (3)
F. R-521-3 2" Dia. (1)
G. R·533-3 Flipper (2)
PANEl TOP PARTS
1. Bottom Arch P-5871-82
2. Shooter Gauge . . . . . . . .P·6359-47
3. Panel Plastics M-1330-180
4. Panel Plastics A-2890-149
5. Thumper Bumper Cap (3) .A-3713·58
6. Rollover Button (7) C·900
7. Target Assy. (Yellow) ASE-2911·21
8. Protective Angle P-7639
9. Ball Guide Assy A·3032-64
10. Ball Guide Assy A-3032-65
11. Thumper Body (31 ASE-2222-4
1 2. Flip pe r & Shaft Assy.. . . .ASE ·2214·29
13. Sp inner & Gate Assy.. . . .ASE -2250-83
14. Spinner & Gate Assy ..... ASE-2250-84
15. Outhole Wire & Bracket .. ASE·2806-21
16 . Target Assy. Red ASE·2911·3
17. Outh 01 e Kicker. . . . . . . .ASE -2694-3
18. Panel. CA-1128·184
19. Rollover Wire Assy. (2) ASE-2806-1
20. Ball Guide Wire (2) M·121-59
21. Ball Guide Assy A-2898-39
22. Flipper & Shaft Assy. (2) .ASE-2214-21
23. Buffer Wire (2) M·121-53
24. Ball Guide Assy A-2989-38
25. Rollover Wire Assy. (2) ASE·2.B06
26. Rollover Wire Assy ASE·2a06-31
27. Ball Ramp (l) P-8155-1
28. Ball Ramp (e) ,P-8155-2
29. Ball Ramp (R) P·B155-3
30. Ball Ramp (Lane) P·8155-4
31. Target Assy. (Red) (2) ASE-2911-31
32. Minipost & Rubber ASE-2836-'
33. Playfield Mylar Overlay .. M·1787-29
WHEN ORDERING PART,
SPECIFY PART NO.
AND NAME OF GAME 51
