#1215 FLASH GORDON o SWITCH ASSEMBLY IDENTIFICATION NUMBERS o INDICATES SWITCH ASSEMBLY
IDENTI FICATION NUMBE RS.
NOTE: CABINET: 07 ,16
DOOR 06,09
10,11,16
D INDICATES SOLENOID
IDENTIFICATION NUMBERS.
NOTE: DOOR: 15
BACKBOX: 16
CABINET: 02
6 INDICATES ASSEMBLY
IDENTIFICATION NUMBERS
1. lnline Drop Target A (Top) ASW·A1·168
2. Inline Drop Target B ASW·A1·168
3. lnline Drop Target C ASW·A1·168
4. Inline Drop Target D (Bottom) ASW·A 1·168
5. lntlne Red Target ASW·A 10·48
6.
7. Ti[t ASW·A1·145
B. Outhote ASW·Al·143
9.
10.
11.
12. Top B Rollover ASW·A 1·206
13. Top A Roll over ASW·A 1·206
14. Spinner ASW·Al·151
15. Side R.O. Button. . . . . . . . . . . ASW·A 1·152
16.
17. 3 Drop Target 3 (Bottom) ASW-A 1·168
18. 3 Drop Target 2 ASW·Al·l68
19. 3 Drop Target 1 (Top) ASW·A 1·166
20.
21.
22.
23.
24. Top Saucer ASW·A1·154
25. Red Side Target ASW·A 10·48
26. Right Out Rollover ASW·A 1-155
27. F[ip Feed Lane (Rt) ASW-Al·155
28. Flip Feed lane ILt) ASW·A1·155
29. Left Outlane ASW·A 1·155
30. Right Side Lane R.O ASW·A1·206
31.
32. Up-Down Saucer ASW-A 1·205
33. 3 Drop Target Rebound ASW·Al0-47
34.
35. Right Slingshot (2) ASW·A10-47
36. Left S[ ingshot (2) . . . . . . . . . . . . . . . . . . ASW-A 10·47
37. Right Side Thumper B ASW·Al1()..5
38. Left Side Thumper 8 .....•............ ASW·A 110-5
39. Top R t , Th umper Bumper. . . ASW·A 110-5
40 .. Top Lt. Thumper Bumper ASW·A 110-5
o SOLENOID AND COIL IDENTIFICATION NUMBERS
1. Outhole Kicker .......•.•.•.•...... AN·26·1200
2. Knocker AR·26·1200
3. Kick Up Saucer AO·30·3000
4. Kick Down Saucer AO-29·2100
5. Left SI ingshat. . . . . . . . . . . . . . . . . . . . . AO·26·1200
6. Right Slinqshot AO-26·1200
7. In line Drop Target Reset NO·26-1900
8. 3 Drop Target Reset NO·26·1900
9. Top Left Thumper Bumper AN·26·1200
10. Top Right Thumper Bumper AN-2.6-1.200
11. Left Side Th urnper Bumper. . AN ·26-1200
12. Right Side Thumper Bumper AN-26-12oo
13. 3 Drop Target 1 (Top) CJ··31·2000
14. 3 Drop Target 2 CJ··31·2000
15. 3 Drop Target 3 (Bottom) CJ·31·2000
16. Coin lockout Door FO·36·7000
17. Flipper 12l , AQ·25·500134·4500
18. Top Saucer ...............••...... AO·27·1300
6. ASSEMBLY IDENTIFICATION NUMBERS
PANEL BOTTOM PARTS
1. Left S!ingshot ASE·2593·6
2. Right Sllnqshot ASE·2593·6
3. ln Line Drop Target , ASE·2993·6
4. 3 Drop Target with Memory , ASE·3038·1
5. Two Way Eject Assy ASE·3054
6. Top Left Thumper Bumper ASE·1567·13
52
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
37
7. Top Right Thumper Bumper .....•..... ASE·1567·13
8. left Side Thumper Bumper ASE·1567·13
9, Right Side Thumper Bumper ASE·1567·13
10, Top Saucer ASE·428-41
11. left Flipper ASE·1587·112
12. Right Flipper ASE·1587·111
