#1198 VIKING o SWITCH ASSEMBLY IDENTIFICATION NUMBERS
o 1. 2 Left & Right R.O. Buttons ASW·A1·152
2. 3 Shooter Lane A.O. Buttons ASW·Al·152
3. Top Single Drop Target ASW·Al·l68
4. Shooter Lane Rollover ASW·A 1·206
5. Drop Target 50 Point Reb. (2) ASW·Al·47
6.
7. Tilt ASW-A1·145
8. Outhole ASW-A 1·143
9.
10.
11.
12. Lower Right Side Target ASW-A 10-48
13 . Flip Feed Lane (Right) ASW·A 1·206
14. Flip Feed Lane (Left) ASW·A 1·206
15. Upper Right Side Target ASW-A 10·48
16.
t7. 4 Drop Target "AU (Bottom) ASW·A1·168
18. 4 Drop Target "B" ASW·A1·168
19 . 4 Drop Target "C" ASW·A 1·168
20. 4 Drop Target " 0" (Top) ASW·A1-168
INDICATES SWITCH ASSEMBLY
IDENTI FICATION NUMBERS.
NOTE: Cabinet: 07 ,16
Door : 06,09
10,11, 16
o INDICATES SOLENOID
IDENTIFICATION NUMBERS
NOTE: Door: 16
Backbox: 17
Cabinet: 02
6. INDICATES ASSEMBL Y
IDENTIFICATION NUMBERS.
21. 1 Drop Target (Top) ASW·A '·168
22. 2 Drop Target (Middle) ASW·A 1·168
23. 3 Drop Target (Bottom) ASW·A1·168
24. Top Target ASW·A10-48
25. 1st Inline Drop Target ASW·A1·168
26. 2nd Inline Drop Target ASW·A1·168
27. 3rd lntlne Drop Target .....•......... ASW·Al·168
28. Inline Back Target ASW·A 10·48
29. 10 Point Rebound (2) ASW·A10-47
30. Saucer ASW·A 1·205
31. Right 0ut lane. . . . . . . . . . . . . . . . . ASW·A 1·206
32. Left Outlane ; ASW-A 1·206
33. Right Spinner ASW·A 1·151
34. Left Spinner ASW·A1·151
35. Right Slingshot (2) ASW·A 10-47
36. Left Slingshot (2) ASW·A10-47
37. Top Thumper Bumper ......•........ ASW·A 110-5
38.
39. Right Thumper Bumper .............• ASW·A 110-5
40. Left Thumper Bumper ASW-A 110·5
o SOLENOID AND COIL IDENTIFICATION NUMBERS
1 . Outhole Kicker AN·26·1200
2. Knocker AR·26-1200
3. Saucer Kick Down AO-29-2100
4. Saucer Kick Up AQ·27·1300
5. Single Drop Target Reset AQ·27·1300
6. 4 Drop Target Reset NO·26·1900
7. 3 Drop Target Reset NO·26·1900
8. In Line Drop Target Reset NO·26·1900
9. Left Thumper Bumper AN-26-1200
10. Right Thumper Bumper AN·26·1200
11. Single Drop Target Pull Down CE·31·2000
12. Top Thumper Bumper AN·26·1200
13. Left Slingshot AN·26·1200
14. Right Slingshot AN·26·1200
15. Coin Lockout Door FO-36-7000
16. Flippers AQ·25·500/34·4500
~ ASSEMBLY IDENTIFICATION NUMBERS
PANEL BOTTOM PARTS
1, Single Drop Target with Memory ASE·2993·10
2. 4 Drop Target ASE·2795-82
3 . 3 Drop Target. ASE·2795-81
4. In Line Drop Target ASE·2993·11
5 . L eft Thumper Bumper ASE·1567·13
6. Right Thumper Bumper ASE·1567·13
7. Top Thumper Bumper ASE·1567·13
36 WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME WHEN ORDERING PART I SPECIFY PART NO. AND NAME OF GAME 53
8. Left Slingshot ASE·2593·6
9. Right Slingshot ASE·2593·6
10. Left Flipper ..........•.......... ASE·1587·112
11. Right Flipper ASE·1587·111
12. Upper Right Flipper. ASE·1587·117
13. Two Way Eject ASE·3054-1
