FRONT CABIND
Front Cabinet,
Assembled
GLASS FRAME,
PARTS RELATED TO
Front Roil Lock Assy.
.
AS-2313-5
Brocket,
Front Ra i I
P-6364-2
Bushing,
Longer
S-231-672
Shorter
S-231-695
Elastic Stop Nut
; .. M-3l9-3
Latch,
Front Rail
P-6365-1
Washer,
5/8 in. diameter
Thicker
(1/16 in.)
P-80l-l07
Th inner (1/32 in.)
P-80l-514
Gloss Frome Assy
AS-2442
Brocket,
Bock
P-7071
Channel,
19-3/4 in. long
M-1450
40-1/4 in. long
M-1450-1
Gloss
G-337
Moulding Assy.,
Front
Ins ide
A-2737-8
Outside (Top)
A-3080
Side
Left
A-3152-1
Right
A-3152
P lug Bumper
R-231-12
Latch Lever
P-6363
See illustration
at right above.
Pivot
Pin
(Glass Frame Support)
S-468-21
Shield,
Glass Frome
Left
P-7061
Right
P-7061-1
See illustration at right above.
Stop Bracket,
Glass Frame
P·6665-249
Support,
Glass Frame
Left
P-7062
Right
P·?062-1
Bushing
(Latch Lever)
S-156-410
P-6363
ILLUSTRA TED
IN REDUCED SIZE
P-7061-1
Leg Bolt Armor
P-3914
Lock Plate (Coin Box)
P-3045-9
Panel Guide Lock .. _ ..•......
P-6646-2
See ill
us trcf ion
below
Panel Guide Lock Assy.,
Left ••... .•. ....•.....
A-3D'?-1
Right .••.•............
A-3D17
See illustration below
ILLUSTRATED
IN REDUCED SIZE
Ponel Support
Bracket
........•.
P-1968-8
Plug Bumper
.•.......... .
R-231-11
Rubber Ring
R- 521-6
SOUNDER ASSY.:
See page 181
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
