Page 203 - 1973_BALLY PARTS CATALOG ASPIRE

FRONT CABINET
Front Cabinet, Unassemb'ed
Ball,
Play, 1-1/16 in. M-168-26
Tilt
MARINER, earlier games+
1·1/16 in M-168-26
FIREBALL later games*
15/16 in. M-168-50
Coin Box components
ROCKET 111*
Coin Box. . . . . . . . . . . . . . . . . . . . . . .. A-2790-25
Coin Box Cover ... . . . . . . . . . . . . . .. P-3089-35
Coin Box Divider. . . . . . . . . . . . . . . .. P·6074-73
THE WIGGLER through" MARINER
Coin Box A-2790-30
Coin Box Cover P-3089-38
Coin Box Divider .. . . . . . . . . . . . . . .. P·6074·82
FI REBALL and later games"
Coin Box A·2790-49
Coin Box Cover . . . . . . . . . . . . . . . . .. P-3089-46
Coin Tray,
2-11/16 in. wide M·1579
3-7/8 in. wide M-I579-1
6-7/8 in. wide M-1579-2
Leg. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. P-4052-S
Leg Adjuster. . . . . . . . . . . . . . . . . . . . . . . . .. M-163-4
Leg Bolt. . . . . . . . . . . . . . . . . . . . . . . . . . . .. M-106-1
Front Door
Also see pages 11·14
ANTI-TILTS: see page 174
COIN HANDLING: see pages 10-33
FASTENERS
Order nuts, screws, washers
by name or description with reference to
(a) Name of game,
(b) Part fastener secures
Front Door
MARINER and earlier games"
Door (wood only)
Single Chute , . . . .. CA-567-166
Double Chute. . . . . . . . . . . . . . . . . . .. CA-567-167
Triple Chute. . . . . . . . . . . . . . . . . . . .. CA-567-168
Door Cover
Single Chute. . . . . . . . . . . . . . . . . . . .. P-5946-20
Double Chute. . . . . . . . . . . . . . . . . . .. P-5946·21
Triple Chute. . . . . . . . . . . . . . . . . . . .. P-5946-17
FIREBALL and later games*
Door Assy., . . . . . . . . . . . . . . . . . . . . . . .. A-3444
Door Back Plate. . . . . . . . . . . . . . . . . . . .. P-7479-2
Hinge Assy, (Door)
MARINER and earlier games*. . . . . . . . .. A-454-79
FIR EBAL L and later games*. . . . . . . . . .. A-45 4·103
Lock (with 2 keys). . . . . . . . . . . . . . . . . . . .. M-281-22
Lock Cam
MARINER and earlier games" P-4005-1
FIREBALL and later games*. . . . . . . . . .. P-4005-4
Lock Mounting
MARINER and earlier games*
Lock Plate . . . . . . . . . . . . . . .. P-3473-2
FIREBALL and later games*
Lock Spacer. . . . . . . . . . . . . . . . . . . .. P-6264-86
REPLAY BUrTON: see page 172
Mounting Board
ALTERNATOR UNITS: see pages 19-22
ANTI-TILT: see page 174
CIRCUIT CONTROLS: see pages 34-166
Counter, Total Play E-130-10
FASTENERS
Order nuts, screws, washers
by name or description with reference to
(a) Name of game
(b) P Part fastener secures
Transformer. . . . . . . . . . . . . . . . . . . . . . . . .. E-122-95
* See chronologi cal list of games , page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
