FRONT CABINET
Front Cabinet, Assembled
ANTI - TILTS:
see page
174
Bal
Control
Plate
P-363-4
When installing Boll Shooter, odjust in hole in
fron t a f Cob inet so th at Shooter Tip is centered
in Bol
Control
Plate, as illustrated below
PLATE (BALL-SHOOTER)
A-S900-1
(Inside of Cabinet)
FASTENERS
Order fasteners (nuts, screws, washers, etc.)
by nome or descr i
ph
on with re
fe
rene e to
(0)
par
t
wh ich fosten er seeu res, (b) nome of game
FLIPPER BUTTON:
see page
245
FRONT DOOR TRIM,
MARINER
and earlier games*
Left. . . . . . . . . . . . .. . . . . . . . . . . . . . . . ..
P-5940-20
Right. . . . . . . . . . .. . . . . . .. . . . . . .. . ..
P-5940-19
Top or Bottom. . . . . . . . . . . . . . . . . . . ..
P-5940-21
FIREBALL
and later games"
Left. . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
P-5940-29
Right. . . . . . . . . . . . . . . . . . . . . . . . . . . ..
P-5940-31
Top
or
Bottom.
. . . . . . . . . . . . . . . . . . ..
P-5940-30
*
See chronolog ical list of games , page 6.
GUIDE ASSY. A-1S40-S
SPRING CUP
P-2879
ONE AT EACH END
OF SPRING
-
RETAINING RING P-2891-8
BALL SHOOTER ASSYS
MARINER
and-earlier games* . . . . . . . . . . ..
AS-2378
As
illustrated above
FIREBALL
and later games
AS-2378-1
Same as AS-2378, excepting
Tip. . . . . . . . . . . . . . . . . . . . . . . . .. . ..
R-I08-4
R-108-4 is recommended replacement
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
