STEPPING UNITS, CONTINUOUS
FASTENERS
Effective with ON BEAM and later games*, game to game variations in
Continuous Stepping Units (other than Match Units) are described on this page.
If port number is not known for variable components in GATORand earlier
games*, order by name with reference to (a) nome of Unit, (b) name of game.
Order nuts, screws, washers by nome with reference to (a) name of Unit,
(b) name of game, (c) port fastener secures
ON BEAM
Space Station Unit
As illustrated. page 113. with
Base Plate Assy
A ·176B
Coil
.
B ·26-1100
Contact Plate (wired) . . .. W -1123
Ratchet
&
Shaft
C -l050
Spring. Extension,
Index Pawl
SP -l00-125
Step-up Arm
SP -l00 -125
Step -up Arm Assy . . . . . ..
A -1765-24
Wiper Assy . . . . . . . . . . ..
AS -l046-570
KING REX
Bonus Unit
See page 119
GALAHAD
CAMELOT
Advance Unit
As illustrated, page 113, with
Base Plate Assy . . . . . . . ..
A -1768 -43
Coil
B -27 -1300
Contact Plate (wired)
W -ll12-2
Ratchet
&
Shaft
C -1050
Spring, Extension
SP -l00-125
Step-up Arm Assy
A-1765-l8
Wiper Assy
AS -l 046-61 0
FIRECRACKER
Firecracker Unit
AS -827-435
As illustrated. page 113 , with
Base Plate Assy
A -1768 -43
Coil
B -26-1100
Contact Plate (wired) .. .. W ·1l23-9
Plunger . . . . . . . . . . . . . ..
S-496-162
Ratchet
&
Shaft
C -1060
Spring, Extension . . . . . ..
SP -l00-125
Step-up Arm Assy
A -1765-19
Wiper Assy . . . . . . . . . . ..
AS-1046-614
*
See chronological
list of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
114
(Pages 115-117 Reserved.)
