Page 126 - Bally 1971 Parts Catalog

SUPER FLIPPER UNITS SEE PAGE 203 FOR VARIATIONS
FLIPPER & PIN ASSYS.
SEE PAGE 203 FOR VARIATIONS
SCREW, NO.6, }'lIN. LONG,
SHAKEPROOF, TYPE 25,
SELF-TAPPING,
CADMIUM PLATED
RUBBER RINGS
SEE PLAYFIELD DIAGRAMS
COMMENCING PAGE 156
FLIPPER BUTTON
RET AINING RING
P-2891-7
FLIPPER BUTTON ASSY. AS-2443
Flipper Button, parts related to
Pal Nut M-1314-2
Switch,
Left Button ASW-A-1010
Right Button ASW- A 10-3
Switch Plate,
Flat P-126-155
Spring P-137-5
SCREWS
Order screws by name or description with ref-
erence to (a) name of game, (b) FI ipper Unit,
(c) left or right, (d) port screw secures.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
202
