INDEX TO ILLUSTRATION, PAGE 202
Base Plate,
Left
P-3691-IS
Right
P-3619-19
Core Plug Assy
A-613-67
SECURED BY
Lockscrew (2 used)
LS-832-5-SIO
Coil
GALAHAD,
later games* .....
" AF-26-750/31-900
See details below for earlier games*
Coil Bracket
P-l OS-53
SECURED BY
Lockscrew (2 used)
" LS-S32-S-SI0
Plunger
,
S-496-167
Guide Ring (not visible)
C-342
o
(2)
®
®
@
Spring, Compression
RollPin
P-1637-1
SP-240
SUPER FLIPPER UNITS
()J)
Lever Arm Assy.,
Left . . . . . . . . . . . . . . . . . . . . ..
A-ISS 9-8
Right
1\-1889-7
@
Set Screw (2 used)
M-1369
@
Bearing, Nylon.
. . . . . . . . . . . . ..
C-649
SECURED BY
Screw (3 used) . . . . . . . . . . . . ..
MS-632-5-510
8
Stop Bracket
P-6256
SECURED BY
Lockscrew (2 used)
LS-832-5-810
@
SwitchBracket
P-126-559
SECURED BY
Lockscrew (2 used)
..
LS-632-3-S11
@
Switch
ASW-A20-1
SECURED BY
Screw (2 used)
MS-540-7-110
@
Switch Plate (Spring)
P-137-5
Effective with ON BEAM and later games*, game to game varia-
tions of Flipper components are listed on this page.
Order components for GATOR and earlier games by name
or description with reference to
(0)
nome of game, (b) name of
Assy., (c) left or right.
Availability of ports for ROCKET III and earlier games*
is not guaranteed.
ON BEAM
Flipper & Pin Assy . . . . . . .
AS -2214-17
As illustrated, page 202, with
Flipper (Orange)
C -610 -11
Flipper Arm A ss y. . . . . .. A-2747-1
Flipper Units,
Left
AS·1 587-50
Right
, AS -1587-49
As illustrated, page 202, excepting
Coil
AF -25-600/31-1000
JOUST
Flipper & Pin Assy
AS -2214·14
A s illustrated, pag e202 ,with
Flipper (Orange) . . . . . . .. C-610 ·611
Flipper Arm Assy . . . . . .. A-2747-4
Flipper Units (Flipper Zipper)
As illustrated, pages206, 207 ,
Switch & Bracket Assy ....
AS -982-588
As descr ibed page 208
BALLYHOO
Flipper
&
Pin Assy
AS-2214 -20
As illustrated, page 202, with
Flipper (Y e llow)
C -611-3
Flipper A rm Assv . .
A -2747 -6
Flipper Units
Le ft
AS-1587 -68
Ri ght
AS-1587 -67
As illustrated ,page202 ,with
COil """"""
AF-27 -775/31-861
KIN(j TUT
Sam eas in BALLYHOO, excepting
Flipper
&
Pin Assy "_" "
AS-2214 -19
Same as in BALLYHOO, exce p ting
Flipper (White)." ... , .. C-611 -5
KIN(j REX
Same as in KING TUT
(jALAHAD,later games*
except as noted
Flipper
&
Pin Assy " .,."
AS -2214-19
As illustrated, page 202, with
Flipper (White).,.
_". ,.
C -611·5
Flipper Arm A ss v.. . , . __ A -2747-6
Flipper Units
Left .. , ... ,_ .. , .' ....
AS -1587-72
Right " ,......... .
AS -1587-71
As illustr a ted ,page 202
4 QUEENS
Flipper & Pin Assy.
Left "
AS-2214-7
As illu s trated ,page202, with
Flipp e r ., ... ..
" ... , C-609-5
Flipp e rArm Assy "'..
A-2747-4
Right
AS -2214-6
Same a sAS·2214 -7 ,e xce pting
Flipper
, . .. C -610-5
Flipper Units (Flipper Zipper)
As illustrated ,pag e s206, 207
Switch
&
Bracket Assy .,.,
AS -982-588
As described, pag e208
*
See chronological
list of games, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
203
