4-STEPS FREE-BALL ESCAPE ASSYS.
AS-2300
in
MAD WORLD
AS-2300-1
in
CAPERSVILlE
SPRING
SP-100-233
r-----------------------,
I
NAME OF COMPONENT
IN
AS-2300
IN
AS-2300-1
I
I
Arm
&
Stud Assy_
A-2870
A-2870-1
I
I
Ball Escapement Plate Assy_ (Bottom) A-2871-2
A-2871-5
I
I
Ball Escapement Plate Assy_ (Center)
A-2871
A-2871-3
I
I
Ball Escapement Plate Assy. (Top)
A-2871-1
Not Used
I
I
I
I
Escapement Bracket Assy.
A-2877
A-2877-1
I
I
Link
P-1973-144 P-6442-13
I
L
~
ARM & STUD ASSY-. ~-
SEE TABLE ABOVE
COIL BRACKET
&
MOUNTING ASSY_
A-2880
CORE-PLUG ASSY.
A-613-33
ROLL PIN
P-1637-10
PLUNGER
S-496-168
LlNK---~
SEE TABLE ABOV~J
LOCKSCREW
LS632-3-510
COIL & BRACKET ASSY.
AS-2299
USED WITH BOTH ABOVE ASSYS.
BALL ESCAPEMENT
PLATE ASSY.
(TOP)
NYLINER
C-537-3
BALL ESCAPEMENT
PLATE ASSY.
(CENTER)
BALL ESCAPEMENT
PLATE ASSY.
(BOTTOM)
ESCAPEMENT BRACKET ASSY.
I
SEE TABLE ABOVE
WHEN ORDERING PART,
SPECIFY PART NO. AND NAME OF GAME
201
