T.7 Sound and Music Test
Once the test name is shown under the Test Menu. press theEnter button. The Sound and Music
Test allows you to check the audio circuits. This test has three modes for testing the sound and
music circuits. Running. Repeat and Stop.
Running
Repeat
Stop
This test steps through a sequence of sounds and music. Pressing the Up or Down
button during this portion of the Sound and Music test allows you to advance to a
particular sound or tune without having to wait for the program to play all the
sounds available in the test. For each name and number that appears in the displays
a sound or tune should be heard. Any other results indicates the system has
detected a problem.
Press the Enter button at any time during the Running test mode to cause the
program to stop and repeat a particular sound or tune. The same sound should
repeat continuously until the Up or Down button is pressed. Any other results
indicates the system has detected a problem.
Press the Enter button at any time during the Repeat test mode to stop this test
altogether. Nothing should be heard. Any other results indicates the system has
detected a problem.
Use the Enter button to return to the Running test mode. or the Escape button to return to the Test
Menu. Once in the Test Menu press the Up button to display the next test. (or the Down button to
return to a previous test). Press the Enter button to activate that test.
T.8 Single Lamp Test
For all lamps. the number on the left indicates
the
column. the number on the right
indicates the row. Example- Lamp 23 means 2nd column. 3rd row.
Once the test name is shown under the Test Menu. press the Enter button. This test allows you to
test each lamp circuit individually. Press the Up or Down button to cycle through this test. For
each name and number that is shown in the displays the corresponding lamp should light. Any
other results indicates the system has detected a problem. Press the Start button to obtain wire
color, connector, and fuse information when the desired lamp is lit.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
T.9 All Lamps Test
Once the test name is shown under the Test Menu, press the Enter button. This test causes all the
controlled lamps to flash at the same time. Every controlled lamp should flash. Any other results
indicates the system has detected a problem.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test,
(or the Down button to return to a previous test). Press the Enter button to activate that test.
The ADDAMS FAMILY 1-18
