T.S Flasher Test
Once the test name is shown under the Test Menu, press the Enter button. This test allows you to
test the flashlamp part of the solenoid circuit exclusively. This test, like the Solenoid Test, has
three test modes Repeat, Stop, and Running. During this test, only one flashlamp circuit should
turn On at a time. If, more then one flashlamp circuit turns On, or stays On, or no flashlamp
circuit turns On at all during the Repeat or Running test modes the system has detected a problem.
Press the Start button to see the wire color, driver number, connector, and fuse information of any
flashlamp circuit when that circuit appears in the displays.
Repeat
Stop
Running
This test allows you to stop and pulse a single flashlamp. Once you have entered
the Flasher Test the name and number of the first flashlamp circuit shows in the
displays and the corresponding bulb(s) flashes. Press the Up or Down button to
cycle through all of the flashlamps circuits one at a time, manually. The same
flashlamp circuit pulses until you press the Up or Down button to move to the next
one. Either, press the Escape button to return to the Test Menu, or press the Enter
button to advance to the next test mode.
This test allow you to stop the Flasher Test at any time. Press the Enter button
during the Repeat test mode. The Flasher Test stops. There should not be any
flashlamp circuit turned On during this test mode. Either press the Escape button
to return to the Test Menu, or press the Enter button to advance to the next test
mode.
This test allows you to cycle through the flashlamps automatically. Press the Enter
button during the Stop test mode. The displays show you the name and number of
the flashlamp currently being pulsed, and the corresponding bulb(s) flashes.
Either press the Enter button to return to the Repeat test mode or, press the Escape button to return
to the Test Menu. Once in the Test Menu, press the Up button to display the next test, (or the
Down button to return to a previous test). Press the Enter button to activate that test.
T.6 General Illumination
Once the rest name is shown under the Test Menu, press the Enter button. This test allows you to
check all of the General Illumination circuits. There are two modes of operation, Stop and Run.
To obtain wire color, driver number, connector, and fuse information, press the Start button when
the desired General Illumination circuit appears in the displays.
Stop
Press the Up or Down buttons to cycle through the General Illumination Test
manually. All illumination is tested first, followed by an individual circuit test.
The circuit name and number shows in the displays while the corresponding lamps
lights. If any other results occur the system has detected an error.
Run
Press the Enter button any time during Stop test mode and the General
Illumination Test cycles through automatically.
For each circuit shown in the
displays the corresponding bulbs should light. If any other results occurs the
system has detected a problem.
Either press the Enter button to return to Stop test mode, or the Escape button to return to the Test
Menu. Once in the Test Menu press the Up button to advance to the next test, (or the Down button
to return to a previous test). Press the Enter button to activate that test.
The ADDAMS FAMILY 1-17
