J116-1 Violet-Brown, Solenoid 1 to Playfield Coil
J 116-2 Not Used
J116-3 Key
J116-4 Violet-Orange, Solenoid 3 to Playfield Coil
J116-5 Not Used
J116-6 Violet-Green, Solenoid 5 to Playfield Coil
J 116-7 Violet-Blue, Solenoid 6 to Playfield Coil
J116-8 Violet-Black, Solenoid 7 to Playfield Coil
J116-9 Violet-Gray, Solenoid 8 to Playfield Coil
J117 Not Used
J118-1 Not Used
J118-2 Violet-Red Solenoid 2 to Backbox Coil
J 118-3 Not Used
J118-4 Key
J118-5 Violet-Yellow Solenoid 4 to Backbox Coil
J119-1 Red-Green, +50V to Lower Right Flipper Coil
J119-2 Red-Green, Loop End from J119-1
J119-3 Key
J119-4 Red-Blue, +50V to Lower Left Flipper
J119-5 Red-Blue, Loop End from J119-4
J119-6 Red-Violet, +50V to Upper Right Flipper Coil
J119-7 Red-Violet, Loop End from J119-6
J119-8 Red-Gray, +50V to Playfield Coil 35 & 36
J 119-9 Red-G ray, Loop End from J 119-8
J120-1 Orange-Gray, Holding, Playfield Coil 36
J 120-2 Not Used
J120-3 Yellow-Gray, Power, Playfield Coil 35
J120-4 Orange-Violet, Holding, Upr Right Flipper Coil
J120-5 Not Used
J120-6 Yellow-Violet, Power, Upr Right Flipper Coil
J120-7 Orange-Blue, Holding, Lower Left Flipper Coil
J 120-8 Not Used
J120-9 Yellow-Blue, Power, Lower Left Flipper Coil
J120-10 Key
J120-11 Orange-Green, Holding, Lwr Right Flipper Coil
J120-12 Not Used
J120-13 Yellow-Green, Power, Lower Right Flipper Coil
J121-1 Yellow-Brown, Lamp Col. 1 to Playfield
J121-2 Yellow-Red, Lamp Col. 2 to Playfield
J121-3 Yellow-Orange, Lamp Col. 3 to Playfield
J121-4 Yellow-Black, Lamp Col. 4 to Playfield
J121-5 Yellow-Green, Lamp Col. 5 to Playfield
J121-6 Yellow-Blue, Lamp Col. 6 to Playfield
J121-7 Yellow-Violet, Lamp Col. 7 to Playfield
J121-8 Key
J121-9 Yellow-Gray, Lamp Col. 8 to Playfield
J122-1 Key
J 122-2 Not Used
J122-3 Yellow-Gray, Lamp Col8 to Coin Door Bd. J3-9
J 123 Not Used
J 124 Not Used
J125-1 Red-Brown, Lamp Row 1 to Playfield
J125-2 Red-Black, Lamp Row 2 to Playfield
J125-3 Key
J125-4 Red-Orange, Lamp Row 3 to Playfield
J125-5 Red-Yellow, Lamp Row 4 to Playfield
J125-6 Red-Green, Lamp Row 5 to Playfield
J125-7 Red-Blue, Lamp Row 6 to Playfield
J125-8 Red-Violet, Lamp Row 7 to Playfield
J125-9 Red-Gray, Lamp Row 8 to Playfield
J126-1 Not Used
J126-2 Not Used
J126-3 Key
J126-4 Not Used
J126-5 Not Used
J 126-6 Not Used
J 126-7 Red-Blue, Lamp Row 6 to Coin Door Bd. J3-1 0
J126-8 Red-Violet, Lamp Row 7 to Coin Door Bd. J3-11
J126-9 Red-Gray, Lamp Row 8 to Coin Door Bd. J3-12
J127-1 White-Green, 9.8VAC from Xformer Secondary
J127-2 White-Green, 9.8VAC Loop End from J127-1
J 127-3 White-Green, 9.8VAC from Xformer Secondary
J127-4 Key
J127-5 White-Green, 9.8VAC Loop End from J127-3
J128-1 White-Red, 16VAC Loop End from J128-2
J 128-2 White-Red, 16VAC from Xformer Secondary
J128-3 White-Red, 16VAC Loop End from J128-4
J128-4 White-Red, 16VAC from Xfonner Secondary
J128-5 Black-Yellow, 16VAC Loop End from J128-6
J 128-6 Black-Yellow, 16VAC from Xformer Secondary
J128-7 Key
J12B-B Black-Yellow, 16VAC Loop End from J128-9
J128-9 Black-Yellow, 16VAC from Xformer Secondary
J 129-1 Red, 9VAC from Xformer Secondary
J 129-2 Red, 9VAC from Xtorrner Secondary
J129-3 Key
J129-4 Blue-White, 13VAC from Xformer Secondary
J129-5 Blue-White, 13VAC Loop End from J129-4
J129-6 Blue-White, 13VAC from Xformer Secondary
J129-7 Blue-White, 13VAC Loop End from J129-6
J 130 Not Used
J131 Not Used
J 132 Not Used
J 133-1 Red-Orange, +50V to Playfield Coils
J133-2 Red-Brown, +50V to Playfield Coils
J133-3 Red-Black, +50V to Playfield Coils
J133-4 Key
J 133-5 Not Used
J 133-6 Red-White, +20V to Playfield Flashlamps
3-26
