J101-1 Gray-Green, +12V to J210-7, J606-7
J101-2 Gray-Green, +12V to J210-6, J606-6
J101-3 Gray, +5V to J210-5, J606-5
J101-4 Gray, +5V to J210-4, J606-4
J101-5 Black, Ground to J210-3, J606-3
J101-6 Key
J101-7 Black, Ground toJ210-1, J606-1
J102 34-Pin Ribbon Cable, Data to/from CPU J211
J103-1 Yellow-White, 6.8VAC from Xformer Secondary
J103-2 White-Brown, 6.8VAC from Xformer Secondary
J103-3 White-Brown, 6.8VAC from Xformer Secondary
J103-4 White-Orange, 6.8VAC from Xformer Secondary
J103-5 White-Yellow, 6.8VAC from Xformer Secondary
J103-6 White-Yellow, 6.8VAC from Xformer Secondary
J 103-7 Orange, 6.8V AC from Xformer Secondary
J 103-8 Not Used
J103-9 Key
J103-10 Green, 6.8VAC from Xformer Secondary
J103-11 Not Used
J103-12 Not Used
J 104 Not Used
J105-1 Brown, Return, G.I. to Coin Door Board J2-5
J 105-2 Not Used
J105-3 Yellow, Return, G.I. to Playfield
J105-4 Key
J 105-5 Not Used
J 105-6 Not Used
J105-7 White-Brown, 6.8VAC, G.I. to Coin Door Bd. J2-3
J 105-8 Not Used
J105-9 White-Yellow, 6.8VAC, G.I. to Playfield
J 105-1 0 Not Used
J105-11 Not Used
J106-1 Brown, Return G.I. to Insert Panel
J 106-2 Not Used
J106-3 Yellow, Return G.I. to Insert Panel
J106-4 Key
J 106-5 Not Used
J106-6 Not Used
J106-7 White-Brown, 6.8VAC, G.I. to Insert Panel
J106-8 White-Orange, 6.8VAC. G.I. to Insert Panel
J106-9 White-Yellow, 6.8VAC, G.I. to Insert Panel
J106-10 White-Green, 6.8VAC, G.I. to Insert Panel
J106-11 White-Violet, 6.8VAC, G.I. to Insert Panel
J 107 Not Used
J 108 Not Used
J109-1 Blue-Green, Solenoid 25 to Playfield Coil
J109-2 Blue-Black, Solenoid 26 to Backbox Motor
J109-3 Blue-Violet, Solenoid 27 to Playfield Coil
J 109-4 Blue-Gray, Solenoid 28 to Playfield Coil
J109-5 Red-Orange Tieback Diode to Sol. 25, 27, 28
J 109-6 Not Used
J109-7 Key
J109-8 Red-Orange Tieback Diode to Sol. 25, 27, 28
J109-9 Red-Orange Tieback Diode to Sol. 25, 27, 28
J110-1 Brown-White to Solenoid 37 to Insert
J110-2 Key
J110-3 Orange-White to Solenoid 38 to Insert
J110-4 Yellow-White to Solenoid 39 to Insert
J 110-5 Green-White to Solenoid 40 to Insert
J111-1 Black-Brown, Solenoid 17 to Playfield Flasher
J111-2 Black-Red, Solenoid 18 to Playfield Flasher
J 111-3 Black-Orange, Solenoid 19 to Playfield Flasher
J111-4 Black-Yellow, Solenoid 20 to Playfield Flasher
J111-5 Blue-Brown, Solenoid 21 to Playfield Flasher
J111-6 Blue-Red, Solenoid 22 to Playfield Flasher
J111-7 Not Used
J111-8 Not Used
J111-9 Key
J111-10 Not Used
J111-11 Not Used
J111-12 Not Used
J111-13 Not Used
J112-1 Not Used
J112-2 Not Used
J112-3 Not Used
J112-4 Key
J112-5 Not Used
J112-6 Not Used
J112-7 Not Used
J112-8 Blue-Orange, Solenoid 23 to Insert Flasher
J112-9 Blue-Yellow, Solenoid 24 to Insert Flasher
J 113-1 Brown-Black, Solenoid 9 Drive to Playfield Coil
J113-2 Key
J 113-3 Brown-Red, Solenoid 10 to Playfield Coil
J113-4 Brown-Orange, Solenoid 11 to Playfield Coil
J113-5 Brown-Yellow, Solenoid 12 to Playfield Coil
J113-6 Brown-Green, Solenoid 13 to Playfield Coil
J 113-7 Brown-Blue, Solenoid 14 to Playfield Coil
J113-8 Brown-Violet, Solenoid 15 to Playfield Coil
J 113-9 Brown-Gray, Solenoid 16 to Playfield Coil
J114 Not Used
J115 Not Used
