J134-1 Not Used
J134-2 Not Used
J 134-3 Not Used
J134-4 Key
J134-S Red-White, +20VDC to Insert Flashlamps
J13S-1 Not Used
J13S-2 Red-Brown +SOV to Backbox Coils
J13S-3 Not Used
J 136 Not Used
J137 Not Used
J138-1 Key
J138-2 Gray-Yellow, +12V to Backbox Coils
J138-3 Black, Ground to Backbox Coils
J138-4 Not Used
J139-1 Key
J139-2 Gray-Yellow +12V to Coin Door Bd. J2-2
J 139-3 Black Ground to Coin Door Bd. J2-1
J 139-4 Not Used
J139-S Black-White to Coin Door Bd. J2-7
J140-1 Key
J140-2 Gray-Yellow, +12V to Backbox Motor
J 140-3 Not Used
J 140-4 Not Used
J141-1 Key
J141-2 Gray-Yellow, +12V to Playfield Switches
J 141-3 Black, Ground to playfield Switches
J 141-4 Not Used
3-27
