Skull Base Assembly
~
,
-,
~
..
' .
2
1
c
··8
Item Part Number
Description
Item Part Number
Description
1 A-20143
Skull Pin Assembly
5 04-10064
Lamp Plate Riser
a) A-20141
Mouth Rivet Assembly
6 H-20164
Cable
b) 02-5176
Skull Pivot Pin
7 17-1116-3
Yellow Jumper 3"
c) 01-13910
Skull Base Plate
8 03-7520-2
Tie-Wrap Nylon 3-7/8"
d) SM-30-1100-DC Coil Assembly
e) 10-424
Spring - Compression
f) 03-8486
Flange - Centering
Associated Assemblies:
g) 4006-01 017 -05 Mach. Screw, 6-32 x 5/16"
h)
A-13735
Coil Bracket Assembly
9
A-20142
Skull Assembly
2 A-20140
Lamp Plate Assembly
10 4006-01 01 7-05 Mach. Screw, 6-32 Phillips
3 04-10098
Back Cover - Skull
Drive Round Head SEMS
4 4006-01017-05 Mach. Screw, 6-32 x 5/16"
~
'~
