A-14615
1-8ank Drop Target Assembly
Item Part Number
Description
Item Part Number
Description
1 03-8750
Target. Flush
18 5070-09054-00
Diode 1N4001
2
A-14617
Bracket & Post Assembly
19 5647-12693-31
Mini Micro Switch
3 4408-01119-00
Nut #8 ESNA
20 01-8600
Switch Insulator
4 A-11397
Stop Bracket Assembly
21 4002-01105-10
Mach. Screw. 2-56 x
5/8"
5
AE-26-1200
Coil Assembly
22 01-8240
Nut Plate
6 01-8413
Bracket & Coil Mounting
23 A-14908
Target K1Down Assembly
7 03-7066-4
Coil Tubing
a) 01-8647-L
Actuator
8
A-11388-2
Plate & Reset Plate Assembly
b) A-15821
Armature Sub-Assembly
9
4700-00072-00
Flat Washer.
17/64
x 1/2 x 22ga.
c) A-14913
Frame & Eyelet Assembly
10 10-392
Spring - Compression
d)
10-363
Extension Spring
11 20-8712-25
Truarc "E" Retaining Ring
e) SM1-26-600
Coil Assembly
12 01-10183
Switch Bracket
f)
4006-01 003- 03
Mach. Screw. 6-32 x 3/16"
13 4006-01 003-03 Mach. Screw, 6-32 x 3/16"
g) 4700-00089-00
Flat Washer, 11/64x7/16x16ga.
14 03-8034
Stop Single Target
h) 4701-00003-00
Lockwasher #B Split
15
4010-01025-14
Mach. Screw, 10-32 x 7/B"
j)
4008-01005-06BR Mach. Screw, 8-32 x 3/8"
16
07 -6688-17N
Rivet. 5/32 x 7/32"
24 03-B630
Actuator Guide
17 10-433
Spring. Extension
25 4700-00003-00
Flat Washer. 1/8 x 9/32 x 21 gao
2-19
