A-19945
Flipper Assembly
~
Hem Part Number
Description
Item Part Number
1 B-13104-R
Flipper Bracket Sub-Assy.
16 4406-01117 -00
2
A-15848-R
Crank Link Assembly, Right
17 4006-01017-04
3
A-12390
Flipper Stop Bracket Assy.
18 4008-01079-05
4
04-10038
Bushing Sleeve Assembly
19 01-9375
5
FL-11629
Flipper Coil Assembly, Blue
20 4701-00003-00
a) 03-7066-5
Coil Tubing
6 01-7695
Solenoid Bracket
7 10-364
Spring
Associated Parts:
8
SW-1A-194
Switch Assembly
(Not Shown)
9
20-6516
Tinnerman Speednut
10 23-6577
Plug Bumper
21 23-6695
11 4105-01019-10
Sh. Metal Screw, #5 x
5/8"
22 20-10136.1-6
12 4701-00002-00
Lockwasher #6 Split
13 401 0-01 066-06
Cap Screw, #10-32 x
3/8"
14 4701-00004-00
Lockwasher #10 Split
15 4006-01 005-06
Mach. Screw, #6-32 x
3/8"
2-15
Description
Nut 6-32 Hex.
Mach. Screw,
#6-32x1/4"
Mach. Screw,
#8-32x5/16"
Switch Mounting Bracket
Lockwasher #8 Split
Flipper Rubber Ring, Red
Flipper w/Shaft-Long (Yellow)
