A-17811
Kicker Arm (Slingshot) Assembly
80
Sf
, , , , , , ,
l
'--
...
,._..._
;
.•..••
~
Associated Parts for Right & Left Kickers:
Item Part Number
Description
1 02-2364
Coil Plunger
2 A-17a1O
Mounting Bracket Assembly
3 A-12664
Kicker Crank Assembly
4 12-6227
Hairpin Clip
5 4700-00030-00
FW, 17/64 x
1/2
x 15ga.
6 03-8085
Armature Link
7 20-8716-5
Roll Pin,
1/8
x
7/16"
Item Part Number
Description
8
8-9362-L-2
B-9362-R-3
a)
A-17808
b)
01-8-508-8
c)
4006-01017-06
d)
4406-01 119-00
e)
AE-26-1200
f)
03-7066
9
10-128
Coil & Bracket Assy., Left
Coil
&
Bracket Assy., Right
Bracket & 8top Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x 3/8"
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
Spring
2-16
,~
