Ball Accelerator Test Continued ...
During this test. the diagnostic test buttons on the coin door act as follows:
Escape -
Returns to the previous menu.
Up
Chooses the next magnet.
Down
Chooses the previous magnet.
Enter
Activates/Deactivates the magnet for acceleration
T.17 Drop Target Test
This test has three modes - Repeat, Stop, and Run. These modes allow the target to be
activated while the state of the drop target's switch is shown on the display. During this test, if
the drop target's switch (#51) does not work, a message, shown on the display. indicates the
broken switch.
Repeat:
The Repeat test pulses either the Drop Target Up coil or the Drop Target Down
coil, until the Up or Down button is pressed to move to the next coil.
Stop:
The drop target coils are not activated.
Run:
The Run test cycles the Drop Target Up coil and the Drop Target Down coil
automatically.
)
,
During this test. the diagnostic test buttons on the coin door act as follows
Escape -
Returns to the previous menu.
Up
During Repeat: changes to the next call.
Down
During Repeat: changes to the previous coil.
Enter
Cycles the test between the three modes: Repeat, Stop, and Run.
T.18 Underground Trough Test
This test may be used to test all of the critical switches in the trough leading from the top
at
the
playfield (behind the drop target and under the skull) to the lower right popper.
The display
shows the four critical switches that are in the ball's path.
During this test, if any of these
switches do not work (#37, #38, #41, or #42), a message, shown on the display. indicates the
broken switch(es).
The test has two modes - Automatic and Manual.
Automatic:
The automatic operation allows a ball to be cycled through the trough
automatically, with the state of each switch being displayed.
Manual:
Manual operation will not eject balls from the right popper or the lower trough; it
relies on the operator to check the switches manually and/or feed balls by hand.
During this test. the diagnostic test buttons on the coin door act as follows:
Escape -
Returns to the previous menu.
Up
Does nothing.
Down
Does nothing.
Enter
Cycles the type of operation between automatic and manual.
Errors dUring automatic operation:
Unable To Load Underground Trough
This error occurs when a ball is plunged from the auto-plunger and
IS
not seen
In
the
underground trough.
1-17
