Underground Trough Test Continued ...
Left Trough Entrance Not Seen
This error occurs during the automatic test when the ball is plunqed and seen by thf~
center entrance opto. but not seen by the drop target entrance.
Center Trough Entrance Not Seen
This error occurs during the automatic test when the ball is plunged and seen by HIe lett
entrance opto and the right popper opto, but not seen by the center trough entrance.
Popper Opto 2 Not Seen
This error occurs during automatic test when the ball
IS
plunged and seen by the center
entrance opto and the right popper 1 opto, but not seen by the right popper 2 opto.
Popper Opto ~ Not Seen
This error occurs during automatic test when the ball is plunged and seen by the center
entrance opto and the right popper 2 opto, but not seen by the right popper 1 opto atter
several seconds.
T.19 Skull Test
This test exercises the skull by cycling through several speech calls.
T.20
Empty
Balls
This test kicks out all balls loaded in troughs, lockups, poppers, and kickouts until no balls rornain
In those locations.
Note - As balls roll down the p/ayfield and into the outhole, they will be continually kicked
out of the trough.
1-18
".
