A-16765 Ball Trough Assembly - Complete
-<ID-
@
~I?:
Item
Part
Number
Description
l.t!mJ.
part
Number
Description
1.
A-16809
Ball Trough Welded Assy.
10. 01-11586
Coil Mtg. Bracket (Bell)
2.
01-11587
Ball Trough Front
11. 4008-01017-05 Mach. Screw, 8-32x5/16 P-RH SEMS
3.
A-6306-2
Bell Armature Assembly
12. 4408-01119-00 Nut 8-32 ESN
4.
AE-26-1500
Coil Assembly
13. 4008-01017-06 Mach. Screw, 8-32x3/8 P-RH SEMS
5.
01-8-508- T
Solenoid Bracket
14. 23-6702
Bumper Plug
6.
03-7067-5
Coil Tubing
15. A-16927
LED 7 Ball Trough Assembly
7.
10-135
Solenoid Spring
16. A-16926
OPTO 7 Ball Trough Assembly
8.
23-6420
Rubber Grommet
17. 4006-01017-06 Mach. Screw, 6-32x3/8 P-RH SEMS
9.
03-8523
Insulator
INDIANA JONES 2-21
