A-16317 Ball Trough Assembly
o
3
4
VIO-GRN
BLU-YEL
_ ' ____ ._ . _
.. _ _. ._ ' o •• __
._,,-
..
, _ - ---------
Item Part Number
Description
Item Part Number
Description
1.
01-11178
Bracket - Ball Trough
10.
AE-26-1500
Coil Assembly
2.
20-8790
Nylined Bearing
11- A-16575
Stop Bracket Assembly
3.
H-16873
Cable Assembly
12.
4010-01006-08
Mach. Screw, #10-32 x 1/2 P-PH-S
4.
A-16909
Photo Transistor Assembly
13.
01-11393
Bracket - Plunger Guide
5.
A-16908
LED Assembly
14.
10-135
Spring
6.
01-11062
Shield Insulator
15.
4006-01003 -04 Mach . Screw, #6-32 x 1/4 P-PH-S
7.
4106-01013 -06 Sh. Metal Screw, #6 x 3/8 P-PH
16.
4410-01132-01
Nut #10-32 ESN
8.
02-4791
Plunger- Trough Coil
17.
20-8712-43
"E"-Ring, 7/16 " Shaft
9.
03-7066-3
Coil Tubing, 1-7/8" Long
INDIANA JONES 2-22
