T.7 Sound and Music Test
The Sound and Music Test checks the audio circuits.
This test has three modes for testing the sound and music circuits, Run, Repeat and Stop.
Run
The Running mode steps through a sequence of sounds and music.
Pressing the Up or Down button during this portion of the Sound and Music test
advances to a particular sound or tune without having to wait for the program to play all the
sounds available in the test.
A sound or tune should be heard for each name and
number that appears in the display. Any other results indicates the system has detected a
problem.
Repeat
Press the Enter button at any time during the Running mode to cause
the program to stop and repeat a particular sound/tune. The same sound should repeat
continuously until the Up or Down button is pressed. Any other results indicates the
system has detected a problem.
Stop
Press the Enter button at any time during the Repeat mode to stop this
test altogether. Nothing should be heard. Any other results indicates the system has
detected a problem.
T.8 Single Lamp Test
The number assigned to each lamp indicates the lamp's position
in the matrix. The number on the left indicates the column. The number on the right indicates the
row. Example - Lamp 23 means 2nd column, 3rd row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through this
test. For each name and number that is shown in the display the corresponding lamp should light.
Any other results indicates the system has detected a problem.
T.9 All Lamps Test
This test causes all the controlled lamps to flash at the same time.
Every controlled lamp should flash. Any other results indicates the system has detected a
problem.
T.10 Lamp and Flasher Test
This test causes all the flash lamps and the controlled
lamps to flash at the same time. The controlled lamps blink, while the flash lamps cycle from
highest to lowest. Any other results indicates the system has detected a problem.
T.11 Display Test
This test automatically checks every dot in the Dot Matrix Display.
A series of patterns appear in sequence. Each pattern turns On and Off a section of dots. Every
dot on the matrix display should be turned On and off during this test.
INDIANA JONES
1-17
