T.4 Solenoid Test
The Solenoid Test has three modes, Repeat, Stop, and Run. Only one
solenoid should pulse at a time. The system has detected a problem if; more then one solenoid
pulses, a solenoid comes On and stays On or, during the Repeat and Run mode, no solenoid
pulses.
Repeat
The Repeat mode pulses a single solenoid. After entering this test,
Solenoid 1 shows in the display and the corresponding solenoid activates. Press the Up
or Down button to cycle through the solenoids, one at a time. The same solenoid pulses
until the Up or Down button is pressed. Either press the Escape button to return to the
Test Menu, or press the Enter button to move to the next mode.
Stop
The Stopped mode halts the Solenoid Test. Press Enter during the
Repeat mode and the Solenoid Test stops. No solenoids should be activated while the
test is stopped. Either press the Escape button to return to the Test Menu, or the Enter
button to move to the next mode.
Run
The Running mode cycles through the solenoids automatically. The
display shows the name and number of the solenoid currently being pulsed.
T.5 Flasher Test
This tests the flash lamp part of the solenoid circuit exclusively. This, like
the Solenoid Test, has three modes: Repeat, Stop, and Run. During this test, only one flashlamp
circuit should pulse at a time. The system has detected a problem if more then one circuit pulses,
a circuit stays On or, during the Repeat and Run mode, no circuit pulses.
Repeat
The Repeat mode pulses a single flashlamp. After entering this test, the
name and number of the first flashlamp circuit shows in the display and the corresponding
bulb(s) flash. Press the Up or Down button to cycle through all of the flashlamps circuits
one at a time. The same circuit pulses until press the Up or Down button is pressed.
Either press the Escape button to return to the Test Menu, or press the Enter button to
advance to the next mode.
Sto p
The Stopped mode halts the Flasher Test. No flashlamp circuit should be
active during this mode. Either press the Escape button to return to the Test Menu, or
press the Enter button to advance to the next mode.
Run
The Running mode cycles through the flash lamps automatically. The
display shows the name and number of the flash lamp circuit currently being pulsed, and
the corresponding bulb(s) flash.
T.6 General Illumination Test
This test checks all of the General Illumination circuits.
There are two modes of operation: Stop and Run.
Stop
Press the Up or Down buttons to cycle through the General Illumination
Test manually. All illumination is tested first, followed by an individual circuit test. The
circuit name and number shows in the display while the corresponding lamps lights. If any
other results occur the system has detected an error.
Run
Press the Enter button any time during Stopped mode and the General
Illumination. Test cycles through automatically. For each circuit shown in the display the
corresponding bulbs should light. If any other results occurs the system has detected a
problem.
