T.12 Flipper Coil Test
The Flipper Coil Test has three modes, Repeat, Stop, and Run.
Only one Flipper should pulse at a time. The system has detected a problem if; more then one
flipper pulses, a flipper comes On and stays On or. during the Repeat and Run mode, no flipper
pulses.
Repeat
The Repeat mode pulses a single flipper. After entering this test, flipper
coil 01 shows in the display and the corresponding coil activates. Press the Up or Down
button to cycle through the flipper coils. one at a time. The same solenoid pulses until the
Up or Down button is pressed. Either press the Escape button to return to the Test
Menu. or press the Enter button to move to the next mode.
Stop
The Stopped mode halts the Flipper Coil Test. Press Enter during the
Repeat mode and the test stops. No coils should be activated while the test is stopped.
Either press the Escape button to return to the Test Menu, or the Enter button to move to
the next mode.
Run
The Running mode cycles through the flippers automatically. The
display shows the name and number of the flipper coil currently being pulsed.
T.13 Ordered Lamps Test
The number assigned to each lamp indicates the lamp's
position in the matrix. The number on the left indicates the column. The number on the right
indicates the row. Example - Lamp 23 means 2nd column, 3rd row.
This test checks each lamp circuit individually. Press the Up or Down button to cycle through the
lamps. Lamps light in a clock-wise or counter clock-wise direction starting from the bottom of the
playfield. Direction depends on which button, Up or Down, is pressed. For each name and
number that is shown in the display the corresponding lamp should light. Any other results
indicates the system has detected a problem.
T.14 Idol Lock Test
This will test the rotary idol ball lock device. It will test to see if the motor
and position switches are working. When first entering this test the idol lock will be automatically
checked. This will test the idol lock to see if it is functioning correctly. If it passes this test a
message will appear on the screen saying so. If it fails then a message will appear showing it
failed. The test will then show an error and may not work correctly until the problem is fixed.
The test switches act as following:
ESCAPE - Returns to the previous menu.
UP - Move to next valid position
DOWN - Move to last valid position
ENTER - Switch between ONCE & CONTINUOUS MODES>
35
~
~
~
~ ~
92
MOTOR ~OFF POS 1
91
•••
~
--0-
MODE ~ONCE
93
26
••
~
r....
·35~· ~·.. ~ ....
·m~~~~.~~
I ~ ~ ~ ~
92
MOTOR~OFF
1
91
~
~
--0-
MODE~ONCE
t
93
I
2E ••.
~
r....~~
~
~ ~~~~~~~.~~~_.
POS2
INDIANA JONES 1-18
