Basic HTML Version
Jl
A-15946
Bridge Driver PCB Assembly
(for mini playfield)
c..
..•
Al
Ul
4N25
+
J1-1 Blue-Black, solenoid 22 drive (Mini Motor Left), from Power Driver Board J126-6
J1-2 Blue-Violet, solenoid 23 drive (Mini Motor Right), from Power Driver Board J126-7
J1-3 Key
J1-4 Black, ground, from Power Driver Board J118-3
J1-5 Gray-Yellow, +12V, from Power Driver Board J118-2
Dl
lN4004
+5VDC
vee
J2-1 Red, To motor
J2-2 Key
J2-3
N/C
J2-4 White, To motor
INDIANA JONES 3-25
