A-13609
3-bank Opto Drop Target PCB Assembly
i~ iOPTO1 i(f)i
@
i(£)iOPTO 2i(f)i
i(£)ioPTO 3i(f)i
~O~
J1
~~
II II II II II II
II
~ OPT02
KEY
5
01
lN4004
R2
1.2Kn
~lEO
J1-1
Black-Gray, switch F7 (Center Drop Bank Right), from Fliptronic II Board J90G-5
J1-2
Black-Yellow, switch F6 (Center Drop Bank Middle), from Fliptronic II Board J905-3
J1-3
Black-Violet, switch F5 (Center Drop Bank Left), from Fliptronic II Board J906-4
J1-4
Orange, column (switch ground), from Fliptronic II Board J905-6
J1-5
Key
J1-6
Black, Ground from Power Driver Board J118-3
J1-7
Gray-Yellow, +12V from Power Driver Board J118-2
INDIANA JONES 3-26
